HXCU-100
sony

Compact Camera Control Unit for HXC-100 cameras



Full HD digital transmission up to 1200m* using standard triax cable

Equipped with the latest Sony-developed digital transmission technology, the HXCU-100 Camera Control Unit (CCU) can transmit high-resolution pictures between the camera and CCU, supporting most live production applications. The HXCU-100 features flexible interfaces of selectable inputs/outputs between HD-SDI and SD-SDI.

* The maximum cable length depends on the camera system configuration, lens type, and the number of cable connections.

Simple studio system with optional remote control

The optional HKCU-FP1 CCU Front Control Panel is also available. When the blank front panel of the HXCU-100 is replaced with the HKCU-FP1, a simple remote control system can be configured. Many functions of the HXC-100 camera can be controlled by the control knobs and switches on the HKCU-FP1.

Highly compact design

The 1.5 RU-size HXCU-100 CCU creates a standardized 19-inch rack system that is ideal for space-limited production areas, such as small control rooms and OB vans.

  • Digital Full HD transmission up to 1200m* using standard triax cable

    The HXCU-100 Camera Control Unit (CCU) offers long cable runs of up to 1200m (3937 feet) via a ø14.5 mm triax cable between the camera and the CCU.

    * The maximum cable length depends on the camera system configuration, lens type, and the number of cable connections.

  • Highly compact design

    The 1.5 RU-size CCU creates a standardized 19-inch rack system that is ideal for space-limited production areas

  • Optional remote control panel to control HXC-100

    The HXCU-100 is compatible with the RCP-100 family of remote control panels. In any case, the optional HKCU-FP1 CCU Front Control Panel can also be used instead of the RCP. When the blank front panel of the HXCU-100 is replaced with the HKCU-FP1, a simple remote control system can be configured. Many functions of the HXC-100 camera can be controlled by the control knobs and switches on the HKCU-FP1.

  • Multi-system input/output interfaces

    The HXCU-100 features flexible interfaces of selectable inputs/outputs between HD-SDI and SD-SDI. Other interfaces include VBS in/out, HD/SD component video output, as well as sync out and mic and prompter inputs.

  • Built-in down converter maximise flexibility

    The HXCU-100 includes a built down-converter to SD providing simultaneous HD and SD outputs.

  • Cross-compatibility with HSC-300 and HXC-D70 cameras

    The HXCU-100 also provides cross compatibility with HSC-300 and HXC-D70 (working with the CA-TX70 digital triax adapter) cameras.

  • Control with Sony Remote Control Panel

    The HXCU-100 can be controlled with RCP-700/900 Series Remote Control panels connected with CCA-5 cable.

  • Optional HZC-RCP5 camera remote control software

    This optional software application allows the user to control most of the parameters of up to five HXC-100/HXCU-100 camera chains from a PC (Windows 7 English version, Service pack 1).

General
Power supply 100 to 240 V AC, 50/60 Hz
Operating temperature 5 °C to 40 °C (41 °F to 104 °F)
Storage temperature -20 °C to +60 °C (-4 °F to +140 °F)
Mass 8.3 kg (18 lb 5 oz)
Input/output connectors
Camera Triax (1) Kings type (for UC model) Fischer type (for CE model)
Intercom/Tally/PGM D-sub 25-pin, female (1) INCOM (PROD/ENG), 4W/RTS/CC, 0 dBu TALLY (R, G) PGM 2 systems, -20/0/+4 dBu
Remote 8pin multi-connector (1)
Trunk D-sub 9-pin, female (1), RS-422A 1 system
Ethernet 8-pin (1)
Input Connectors
AC input 100 to 240 V AC
Serial return input BNC type (2) HD-SDI: SMPTE 292M, 0.8 Vp-p, 75 Ω, 1.485/1.4835 Gbps bit rate SD-SDI: SMPTE 259M, 270 Mbps bit rate HD-SDI/SD-SDI selectable
VBS return input BNC type (2) VBS: 1.0 Vp-p, 75 Ω
Reference input BNC type (2), loop-through HD: SMPTE 274M, tri-level sync, 0.6 Vp-p, 75 Ω SD: Black burst (NTSC: 0.286 Vp-p, 75 Ω; PAL: 0.3 Vp-p, 75 Ω)
Prompter input BNC type (2), loop-through, VBS signal, 1.0 Vp-p, 75 Ω, 1 ch
Mic remote D-sub 15-pin, female (1)
Output connectors
Mic output XLR 3-pin, male (2), 0/-20 dBu
WF remote D-sub 15-pin, female (1)
HD-SDI/SD-SDI output BNC type (2) HD-SDI: SMTPE 292M, 0.8 Vp-p, 75 Ω, 1.485/1.4835 Gbps bit rate SD-SDI: SMPTE 259M, 0.8 Vp-p, 75 Ω, 270 Mbps bit rate HD-SDI/SD-SDI selectable
HD-SDI/SD-SDI monitor output BNC type (2) HD-SDI: SMTPE 292M, 0.8 Vp-p, 75 Ω, 1.485/1.4835 Gbps bit rate SD-SDI: SMPTE 259M, 0.8 Vp-p, 75 Ω, 270 Mbps bit rate HD-SDI/SD-SDI selectable
Pr/R/R-Y, Y/G/Y, Pb/B/B-Y HD Component video: Y (100% white): 0.7 Vp-p, Pr/Pb (75% color bar): 0.7 Vp-p, 75 Ω HD RGB video R/G/B (100% white): 0.7 Vp-p, 75 Ω SD Component video: Y (100% white): 0.714 Vp-p, Pr/Pb (75% color bar): 0.756 Vp-p, 75 Ω SD RGB video R/G/B (100% white): 0.7 Vp-p, 75 Ω
VBS OUT BNC (2), VBS 1.0 Vp-p, 75 Ω
PIX OUT BNC (1), VBS/R/G/B (VBS 1.0 Vp-p, 75 Ω)
WF OUT BNC (1), VBS/SEQ/R/G/B (VBS 1.0 Vp-p, 75 Ω)
Sync out BNC type (1) HD: BTA-S001A, tri-level sync, 0.6 Vp-p, 75 Ω SD: composite sync, 0.3 Vp-p, 75 Ω HD SYNC/SD SYNC selectable
WF mode 4-pin (1)



HXCU-100

Model: HXCU-100
