9-540mm XJ60x9BIE-D / LO DIGISUPER
canon

2/3″ 60x HD Field Lens



  • Built-In Optical Shift Image Stabilizer
  • Constant Angle Focusing System (CAFS)
  • 60x Zoom
  • Micro Computer Controlled Turret
  • Prevents Ghosting & Flare
  • High Resolution Iris Control
  • Digital Servo System
  • HD Optical Performance
  • Ergonomic & Ecological Design

Image Format 2/3"
Aspect Ratio 16:9
Focal Length Range 9-540 mm
Zoom Ratio 60x
Maximum Relative Aperture 1:1.7 at 9-306 mm
Maximum Speed Zoom 0.6 sec Focus: 0.8 sec
Angular Field of View 56.1 x 33.4° at 9 mm 1.02 x 0.57° at 540 mm
Minimum Object Distance (M.O.D.) 9.19' (2.80 m)
Object Dimensions at M.O.D. 104.37 x 58.7” (2,651.0 x 1,491.0 mm) at 9 mm 1.77 x 0.98” (45.00 x 25.00 mm) at 540 mm
Size (WxHxL) 9.9 x 10.1 x 21.6" (250.6 x 255.5 x 547.8 mm)
Weight 43.78 lb (19.90 kg)
